B_1.0
PRODUCT OVERVIEW
| Interface Type: |
BMA |
| Gender: |
Female |
| RoHS Certificate: |
Compliant |
| Interface Standards: |
MIL-STD-348A |
DOWNLOADS
PRODUCT SPECIFICATIONS
| Technical Data |
| Impedance: |
50Ohm |
| Frequency Range: |
0 ~ 18GHz |
| Insulation Resistance: |
≥5000MΩ |
| Withstanding Voltage: |
500V |
| Temperature Range: |
-65 °C ~ +165 °C |
| Weight: |
25g |
| Durability (Matings): |
>500 |
|
|
| Material Data |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Beryllium Copper Alloy |
Gold plating |
| Body: |
Brass |
Nickel plating |
| Flange: |
Brass |
Tri-metal plated |
| Outer Contact: |
Beryllium Copper Alloy |
Gold plating |
| Insulator: |
PTFE |
|
