PN: P-3.5M-3.5M-146 测试2
| Product Overview | |
| Interface Type: | SMA to 3.5mm |
| Gender: | SMA male to 3.5mm male |
| RoHS: | Compliant |
| Product Specifications | |
| Technical Data | |
| Impedance | 50Ohm |
| Frequency Range | DC to 67GHz |
| VSWR | 1.25:1 |
| Temperature Range | -55 °C to +165 °C |
| Weight | 6g |
| Durability(Matings) | >500 |
| Material Data | |
| Piece Part | Base Material |
| Center Contact | Beryllium Copper Alloy |
| Body | Stainless Steel(SUS303) |
| Insulator | PEI |
